The ON Semiconductor 2SD1685G is a high-performance NPN bipolar power transistor designed for use in a wide range of electronic applications. This versatile component is ideal for power amplification and switching, providing reliable operation in various circuits. With its robust construction, the 2SD1685G is engineered to deliver stable performance under challenging conditions, making it a preferred choice for designers and engineers.

Key Features

• High Current Capacity: The 2SD1685G can handle high levels of current, making it suitable for power regulation and management tasks in electronic devices.
• Low Saturation Voltage: This transistor has a low collector-emitter saturation voltage, which enhances its efficiency by minimizing power loss during operation.
• Fast Switching Speed: It is designed for quick switching, allowing for efficient operation in circuits that require rapid state changes.
• High Power Dissipation: With an impressive power dissipation capability, the 2SD1685G can withstand higher levels of power without compromising its performance or longevity.

Applications

The 2SD1685G is suitable for a broad range of applications, including:

• Power supplies
• DC-DC converters
• Motor controllers
• Audio amplifiers
• Switching regulators
• General-purpose amplification

Specifications

Parameter Value Collector-Base Voltage (VCBO) 60 V Collector-Emitter Voltage (VCEO) 50 V Emitter-Base Voltage (VEBO) 5 V Collector Current (IC) 3 A Power Dissipation (PD) 25 W Operating Temperature Range -55°C to +150°C

The 2SD1685G from ON Semiconductor is a reliable and efficient solution for your power transistor needs, ensuring high-quality performance for a diverse array of electronic applications.
