ON Semiconductor 74ALVC16245GX: 16-Bit Transceiver with Direction Pin

The ON Semiconductor 74ALVC16245GX is a high-performance, 16-bit transceiver that is designed to address the needs of high-speed bidirectional communication between data buses. This integrated circuit is part of the advanced low-voltage CMOS (ALVC) family, which is known for its low power consumption and high-speed operation. The 74ALVC16245GX is ideal for applications that require efficient data transfer and interfacing between different voltage domains in telecommunications, computing, and industrial equipment.

Key Features:

• High-Speed Data Transfer: The device supports data transfer rates that are compatible with high-speed operation, making it suitable for the latest system requirements.
• Low-Voltage Operation: It operates at a nominal supply voltage of 2.3V to 3.6V, which allows for reduced power consumption and compatibility with low-voltage logic levels.
• Directional Control: A direction pin (DIR) provides control over the direction of data flow, enabling the device to act either as a transmitter or receiver.
• Bus-Hold Circuitry: Integrated bus-hold circuitry on the data inputs eliminates the need for external pull-up or pull-down resistors, simplifying board design and reducing component count.
• Output Enable (OE) Feature: The output enable input allows the user to place the I/O ports in a high-impedance state, thus avoiding bus contention.
• Wide Bus Compatibility: The 74ALVC16245GX is designed to interface with 16-bit data buses, offering wide compatibility with microprocessors and digital signal processors.

Applications:

The ON Semiconductor 74ALVC16245GX is versatile and can be used in a variety of applications including:

• Data communication systems
• Signal bridging between different logic domains
• Memory interfacing
• Extension of bus lengths
• Microprocessor or microcontroller-based systems

The 74ALVC16245GX is available in a fine-pitch surface-mount package, which makes it suitable for use in space-constrained applications. Its performance and features ensure that it is a reliable and efficient solution for modern digital systems requiring high-speed, low-power, and bidirectional data bus communication.
