ON Semiconductor AR0135CS2C19SUEA0-DRBR - CMOS Image Sensor

The AR0135CS2C19SUEA0-DRBR from ON Semiconductor is a high-performance 1/3-inch CMOS digital image sensor with an active-pixel array of 1280H x 960V. It incorporates a new innovative global shutter pixel design optimized for accurate and fast capture of moving scenes. The sensor produces clear, low-noise images in both low-light and bright scenes, making it an excellent choice for a variety of demanding applications.

This sensor operates at a maximum frame rate of 60 frames per second (fps) at full resolution, with a pixel size of 3.75 µm x 3.75 µm, delivering high image quality and superior light sensitivity. It also supports a wide range of industry-standard interfaces, including a 4-lane Serial Camera Control Bus (SCCB) for advanced camera control, a HiSPi interface capable of handling high data rates, and a simple two-wire I2C interface for lower data rate requirements and basic configuration.

The AR0135CS2C19SUEA0-DRBR is designed with ON Semiconductor's advanced pixel technology, providing several key features such as on-chip binning and windowing capabilities for flexibility in image control and processing, as well as context switching capabilities which allow for rapid changes between predetermined configurations. This level of control makes it an ideal sensor for machine vision, industrial automation, security and surveillance, and automotive applications, where high speed and image clarity are essential.

The sensor is available in a monochrome version, which is particularly useful in environments where color information is not essential but light sensitivity and detail are paramount. Its compact design and low power consumption also make it suitable for portable and space-constrained applications. The AR0135CS2C19SUEA0-DRBR is a testament to ON Semiconductor's commitment to providing advanced imaging solutions that meet the evolving needs of the technology sector.

With its robust design and cutting-edge features, the AR0135CS2C19SUEA0-DRBR CMOS image sensor stands out as a versatile and reliable component for your next imaging project, ensuring high-quality captures in a wide range of conditions and applications.
