The BCP56-16T1G from ON Semiconductor is a robust NPN bipolar junction transistor (BJT) designed to handle medium power applications with efficiency and reliability. This versatile component is a staple in electronic circuits, offering high current gain and low saturation voltage, making it an ideal choice for amplification and switching applications.

Key Features

• High Current Capability: With a collector current rating of up to 1 A, the BCP56-16T1G can drive moderate loads, suitable for a wide range of applications.
• Medium Power Handling: This transistor can dissipate up to 1.25 W of power, providing a good balance between compactness and power handling.
• Low Saturation Voltage: The low V_CE(sat) ensures efficient operation, minimizing power losses during switching and amplification.
• High Performance: The device offers excellent gain characteristics with a DC current gain (h_FE) range of 100 to 250 at 500 mA, ensuring a consistent performance across various conditions.
• Temperature Range: Capable of operating within a temperature range of -55°C to +150°C, making it suitable for harsh environments.

Applications

The BCP56-16T1G transistor is commonly used in a variety of applications including, but not limited to:

• Power Management Circuits
• Linear Amplifiers
• Switching Regulators
• Driver Stages in Hi-Fi Amplifiers and TV Sound Outputs
• Signal Processing

Package and Quality

Encased in a SOT-223 surface-mount package, the BCP56-16T1G is designed for optimal thermal performance and space-saving on PCBs. ON Semiconductor adheres to stringent quality standards, ensuring that each transistor meets the high reliability and performance standards expected in professional electronic components.

Environmental Compliance

The BCP56-16T1G is a Pb-free device and fully compliant with the RoHS directive, making it an environmentally friendly choice for electronic designs.
