Introducing the CM2020-01TR HDMI Transmitter Port Protection and Interface Device

The CM2020-01TR from ON Semiconductor is a cutting-edge solution designed to protect and interface HDMI transmitter ports. This device is specifically tailored to safeguard the High-Definition Multimedia Interface (HDMI) against Electrostatic Discharge (ESD) and Cable Discharge Events (CDE), ensuring the integrity and longevity of your high-speed digital interfaces.

Key Features

• Integrated Protection: The CM2020-01TR comes with integrated ESD protection diodes for all high-speed data lines, providing robust protection against static discharge and transient voltage spikes that can cause permanent damage to sensitive circuitry.
• High-Quality Signal Integrity: With its low capacitance design, this device ensures that the high-speed digital signals are transmitted without significant distortion, maintaining the quality and reliability of audio and video signals.
• Compliance with HDMI Standards: This device is designed to meet the HDMI 1.3 specification, supporting a full range of HDMI functions including the Deep Color and x.v.Color features.
• Optimized Layout: The CM2020-01TR is offered in a space-saving TSSOP package, making it ideal for use in space-constrained applications such as portable electronics, set-top boxes, and digital TVs.

Applications

The ON Semiconductor CM2020-01TR is suitable for a variety of applications where HDMI interfaces are used, including:

• High-definition televisions (HDTVs)
• Digital video recorders (DVRs)
• Blu-ray and DVD players
• Game consoles
• Personal computers and laptops
• Professional video equipment

Technical Specifications

With an operating temperature range of -40°C to +85°C, the CM2020-01TR is built to perform reliably in diverse environments. Its low stand-off voltage ensures minimal signal attenuation, while the integrated pull-up resistors on the DDC (Display Data Channel) lines provide a complete HDMI port interface solution.

Whether you're a manufacturer looking to enhance the protection of your HDMI-enabled devices or a designer seeking a reliable HDMI interface solution, the CM2020-01TR from ON Semiconductor is an excellent choice that combines performance, protection, and practicality.
