The M74VHC1GT125DF1G is a high-performance, single-gate CMOS logic level shifter manufactured by ON Semiconductor, designed to address the needs of modern electronics where low power consumption and high speed are paramount. This device is ideal for multi-voltage applications, interfacing between different logic voltage levels ranging from 1.65V to 5.5V.

Features

• Logic Level Translation: Capable of translating signals between different voltage domains, ensuring compatibility between various logic families.
• High Speed: Propagation delay times are minimized, making this device suitable for high-frequency applications.
• Low Power Consumption: Designed for low dynamic and static power, contributing to energy-efficient designs.
• Power Down Protection: Inputs and outputs are protected against high impedance states, ensuring device integrity during power-down scenarios.
• Multiple Package Options: Available in a variety of packages including the ultra-small DFN package, providing flexibility for different design constraints.

Applications

• Logic level conversion for microcontrollers
• Signal interfacing between different voltage domains
• Portable and battery-powered electronics
• Data communication and telecommunication systems
• Computing and storage platforms where multiple voltage levels are present

Technical Specifications

Parameter Value Supply Voltage (V<sub>CC) 1.65V to 5.5V Input Voltage (V<sub>IN) 0V to 5.5V Output Voltage (V<sub>OUT) 0V to V<sub>CC Operating Temperature -55°C to +125°C Mounting Type Surface Mount Package / Case DFN-6

The ON Semiconductor M74VHC1GT125DF1G stands out for its versatility and performance, making it an excellent choice for designers looking to create robust, multi-voltage level electronic systems.
