ON Semiconductor MBR130T1G Schottky Barrier Rectifier

The MBR130T1G is a state-of-the-art Schottky Barrier Rectifier designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This device is engineered to offer low forward voltage drop, high surge capability, and a significant reduction in power losses, making it an ideal choice for high-efficiency power management applications.

Key Features

• Low Forward Voltage Drop: The MBR130T1G boasts a low forward voltage drop, which enhances system efficiency by reducing the power dissipation during operation.
• High Surge Capability: This rectifier can withstand high surge currents, ensuring reliability and robustness in demanding situations.
• Guard-Ring for Stress Protection: A built-in guard-ring provides enhanced ruggedness and long-term reliability by protecting against voltage spikes and other stress factors.
• Power Surface Mount Package: The MBR130T1G comes in a compact SOD-123 package, saving valuable board space while allowing for easy integration into various circuit designs.
• Environmentally Friendly: It is a Pb-free device and is RoHS compliant, making it an environmentally friendly option for electronic devices.

Applications

The MBR130T1G is suitable for a wide range of applications, including:

• Low Voltage, High Frequency Inverters
• Free Wheeling
• DC/DC Converters
• Power Supply Applications
• Reverse Battery Protection

Technical Specifications

Parameter Value Package SOD-123 Peak Repetitive Reverse Voltage 30 V Average Rectified Forward Current 1 A Operating Junction Temperature -55°C to +150°C

With its combination of efficiency, reliability, and compact form factor, the MBR130T1G from ON Semiconductor is an excellent choice for designers looking to optimize their power management systems. Its adherence to environmental standards further underscores its suitability for modern electronic designs.
