The MBR20200CTG is a high-performance Schottky Barrier Rectifier designed by ON Semiconductor, renowned for its efficiency and reliability in power conversion applications. This rectifier is engineered to cater to a wide array of requirements, making it a versatile component suitable for various electronic devices and power systems.

Key Features:

• Voltage and Current Ratings: This device is capable of withstanding a maximum repetitive peak reverse voltage of 200V, with an average forward rectified current of 20A at TL (lead temperature) of 105°C, making it suitable for high voltage applications.
• Low Power Loss/High Efficiency: The MBR20200CTG is optimized for low forward voltage drop without compromising its ability to conduct high current levels. This characteristic ensures high efficiency and minimizes power loss during operation.
• High Surge Capacity: With its superior surge handling capability, this rectifier can withstand high surge currents, providing robust protection against transient voltage spikes and enhancing the durability of the end application.
• Thermal and Mechanical Characteristics: It features a maximum operating junction temperature of 150°C and a storage temperature range from -65°C to 175°C, ensuring stability and performance under extreme conditions. The package is TO-220AB, which offers excellent thermal conduction properties.
• Guard Ring Die Construction: The guard ring design provides transient protection and makes the device highly reliable in critical applications.

Applications:

The MBR20200CTG is ideal for use in a variety of applications, including:

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• Power management in portable and consumer electronics

Quality and Environmental:

ON Semiconductor is committed to providing environmentally friendly solutions. The MBR20200CTG is RoHS compliant and free from hazardous substances, aligning with global standards for environmental conservation.

Conclusion:

With its robust design, high efficiency, and versatile application range, the MBR20200CTG from ON Semiconductor stands out as a superior choice for designers looking for a reliable Schottky Barrier Rectifier. Its performance characteristics ensure that it can meet the rigorous demands of modern electronic systems.
