ON Semiconductor MBRD660CTT4G - Schottky Barrier Diode

The MBRD660CTT4G is a high-performance Schottky Barrier Diode designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This diode is engineered primarily for use in power management applications, where it offers a blend of low forward voltage drop and high current handling capabilities.

Key Features

• Low Forward Voltage Drop: The MBRD660CTT4G is designed to have a low forward voltage drop, which improves system efficiency and reduces thermal issues in operation.
• High Surge Capacity: With its robust construction, the diode can handle high surge currents, making it suitable for applications requiring a high level of reliability during surge conditions.
• Power Dissipation: This device can dissipate up to 3.75 watts of power, which contributes to its ability to handle high current applications without compromising performance.
• Dual Diode Configuration: The component features a dual diode common cathode configuration, which is beneficial for simplifying designs and reducing component count in circuits.

Applications

The MBRD660CTT4G is versatile and can be used in a variety of applications, including:

• Switch Mode Power Supplies (SMPS)
• DC-DC Converters
• Free-Wheeling Diodes in Power Supplies
• Polarity Protection Applications
• Power Factor Correction (PFC) Circuits

Specifications

With a maximum repetitive reverse voltage (Vrrm) of 60 volts and a forward continuous current (If) of 6 amperes, the MBRD660CTT4G is capable of supporting a wide range of power requirements. The device is available in a DPAK-3 package, which is known for its compact size and ease of mounting on printed circuit boards.

ON Semiconductor's commitment to quality ensures that the MBRD660CTT4G meets the stringent requirements of the electronics industry, providing a reliable and efficient solution for power management challenges.
