ON Semiconductor MBRM120LT1G - Schottky Barrier Rectifier

The MBRM120LT1G from ON Semiconductor is a highly efficient, surface-mount Schottky Barrier Rectifier designed for applications requiring low voltage, high-frequency rectification, and free-wheeling in power supplies, inverters, and other diverse electronics systems.

Key Features

• Low Forward Voltage Drop: The device offers a very low forward voltage drop, which results in reduced power loss and improved efficiency, making it ideal for high-efficiency power management applications.
• High Current Capacity: With a continuous forward current rating of 1 A, the MBRM120LT1G can handle a significant amount of current for its size, which is beneficial for compact designs.
• Power Surface Mount Package: Enclosed in a SOD-123 package, it is optimized for automated assembly processes and occupies minimal board space.
• Guardring for Overvoltage Protection: The inclusion of a guardring enhances the device's ruggedness by providing overvoltage protection, which is crucial for reliability in sensitive electronics.
• Low Power Loss/High Efficiency: Its low power loss and high efficiency are tailored for use in low voltage, high-frequency inverters, free-wheeling, and polarity protection applications.
• High Surge Capability: The MBRM120LT1G can withstand high surge currents, which is an essential feature for applications that may experience sudden surges in power.

Applications

The MBRM120LT1G is versatile and can be used in various applications, including:

• Switching power supply
• Converters
• Free-Wheeling diodes
• Reverse battery protection
• DC-DC converters
• Automotive applications

Specifications

Some of the electrical characteristics of the MBRM120LT1G include:

• Package: SOD-123
• Peak Repetitive Reverse Voltage: 20 V
• Average Rectified Forward Current: 1 A
• Operating Junction Temperature: -55°C to +150°C

ON Semiconductor's commitment to quality and performance is evident in the MBRM120LT1G Schottky Barrier Rectifier, making it a reliable choice for designers and engineers looking for a robust and efficient rectification solution.
