ON Semiconductor MC34072DR2G Overview

The MC34072DR2G is a high-performance operational amplifier (op-amp) produced by ON Semiconductor, a leading supplier in the semiconductor industry. This op-amp is designed to offer a blend of speed, precision, and power efficiency, making it an ideal choice for a wide range of electronic applications. With its dual amplifiers, the MC34072DR2G is housed in an 8-SOIC package, ensuring a compact footprint suitable for space-constrained designs.

Key Features

• Extended Voltage Range: The MC34072DR2G operates at a supply voltage range from 3V to 44V, accommodating a variety of power requirements for both single and split power supplies.
• High Slew Rate: With a slew rate of 13 V/µs, this op-amp provides rapid voltage changes, making it suitable for fast signal processing tasks.
• Large Gain Bandwidth Product: It offers a gain bandwidth product of 4.5 MHz, allowing the amplifier to handle a wide range of frequencies while maintaining a stable gain.
• Low Input Offset Voltage: The device features a low input offset voltage, which minimizes error in precision applications.
• Output Short-Circuit Protection: The MC34072DR2G is equipped with output short-circuit protection, enhancing its reliability and robustness in adverse conditions.

Applications

The versatile nature of the MC34072DR2G makes it suitable for an array of applications, including:

• Analog signal conditioning
• Audio processing
• Active filters
• Industrial control systems
• Instrumentation
• Power supply control

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The MC34072DR2G op-amp is no exception, with its manufacturing process designed to ensure reliability and performance consistency. This commitment to quality makes the MC34072DR2G a trusted choice for engineers and designers looking for a dependable op-amp solution.

Environmental Considerations

The MC34072DR2G from ON Semiconductor is also designed with environmental considerations in mind. It is a Pb-free device and is compliant with RoHS standards, which means it meets the European Union's restrictions on the use of certain hazardous substances in electrical and electronic equipment.
