The ON Semiconductor MC74LCX07DTR2 is a quintessential component for modern electronic designs requiring low-voltage operation and bidirectional interface communication with high-drive capabilities. This device is part of ON Semiconductor's LCX family, designed to provide optimal performance in 3.3V LVTTL/LVCMOS systems while maintaining 5V TTL compatibility.

Key Features

• Low-Voltage Operation: The MC74LCX07DTR2 operates at a voltage range of 2.3V to 3.6V, making it suitable for low-voltage applications and ensuring power efficiency.
• High Drive: With its ability to source or sink 24 mA, this buffer/driver can drive large capacitive loads, making it ideal for driving high-capacitance lines and buffering clock signals.
• 5V Tolerant Inputs: The inputs can tolerate 5V signals, allowing interface with 5V logic without the need for external components, simplifying design and reducing component count.
• Power-Down High-Impedance Inputs and Outputs: This feature ensures that the device does not load the system during power down, providing better system power management.
• Multiple Package Options: Available in TSSOP-14 package, it offers a compact footprint for space-constrained applications.

Applications

The versatile MC74LCX07DTR2 is suitable for a wide range of applications, including:

• Memory Address Driving
• Bus Interface/Buffering
• Signal Distribution and Generation
• Level Shifting for Mixed-Voltage Systems
• Clock and Data Driver for 3.3V Systems

Technical Specifications

The MC74LCX07DTR2 is characterized for operation from -40°C to +85°C. It is offered in lead-free, RoHS-compliant packaging, reflecting ON Semiconductor's commitment to environmentally friendly manufacturing.

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MC74LCX07DTR2 is no exception. It is produced under stringent quality control measures to ensure reliable performance in critical applications.
