ON Semiconductor MC74VHC1G08DFT2G Single 2-Input AND Gate

The ON Semiconductor MC74VHC1G08DFT2G is a high-performance, single 2-input AND gate designed to meet the requirements of low-power and high-speed operation in modern electronic systems. This advanced logic gate is part of ON Semiconductor's VHC family, which is renowned for its low voltage, high-speed characteristics suitable for battery-powered and portable applications.

Constructed with silicon gate CMOS technology, the MC74VHC1G08DFT2G offers significant power savings compared to traditional TTL logic without sacrificing speed. It operates with a power supply range from 2V to 5.5V, providing flexibility for various design requirements and ensuring compatibility with a wide range of other logic families when used with suitable pull-up resistors.

The device features a ±24mA output drive capability at 3.3V, which allows for high drive currents, making it suitable for driving heavier loads. Additionally, the MC74VHC1G08DFT2G has a high noise immunity characteristic of CMOS devices, ensuring stable operation in noisy environments.

ON Semiconductor has packaged the MC74VHC1G08DFT2G in a compact SC-88A (SOT-353) package, which is ideal for space-constrained applications. The small footprint of the package does not compromise its performance and reliability, making it a preferred choice for high-density electronic assemblies.

Key features of the MC74VHC1G08DFT2G include:

• Logic Type: 2-Input AND Gate
• Supply Voltage Range: 2.0V to 5.5V
• Output Current: ±24mA at 3.3V
• Propagation Delay Time: 4.3ns at 5V
• Operating Temperature: -55°C to +125°C
• Package: SC-88A (SOT-353)

This device is well-suited for a variety of applications, including but not limited to logic level translation, power management, and signal gating. Its robust design ensures that it can meet the strict requirements of industrial, automotive, and consumer electronics markets.

With the MC74VHC1G08DFT2G, ON Semiconductor continues its commitment to providing high-quality, reliable components for the electronics industry. Designers can rely on this AND gate to deliver consistent performance and help streamline their product development process.
