ON Semiconductor MM74C906MX: Robust High Voltage Open-Drain MOSFET

The MM74C906MX from ON Semiconductor is a high voltage, open-drain n-channel MOSFET that is an integral component for a wide range of electronic applications. This robust transistor is designed to handle high voltage operations, making it suitable for interfacing with TTL levels, while also possessing the ability to drive large loads with a minimal input current requirement.

Key Features:

• High Voltage Tolerance: The MM74C906MX can sustain high voltage levels, which ensures compatibility with various TTL and CMOS logic levels.
• Open-Drain Output: The open-drain configuration allows for the connection of different voltage levels to the output without causing damage. It also enables the MM74C906MX to be used in wired-AND logic configurations.
• Low Input Current: This MOSFET is designed to operate with very low input currents, thereby conserving power and reducing the overall energy consumption of the system.
• Durable Design: ON Semiconductor's commitment to quality means that this component is built to last and withstand the rigors of industrial applications.

Applications:

The versatility of the MM74C906MX makes it an excellent choice for various applications, including:

• Logic level conversion
• High voltage line drivers
• Relay drivers
• Lamp drivers
• Memory drivers
• Switching power supplies

Technical Specifications:

The MM74C906MX boasts a comprehensive set of technical specifications that make it a reliable and efficient choice for designers:

• Supply Voltage Range: 3V to 15V
• Output Voltage: 30V
• Output Current: 25mA
• Input Current: 1µA (max)
• Operating Temperature: -55°C to +125°C

With its robust design and high voltage capabilities, the MM74C906MX from ON Semiconductor is a must-have for any electronic project requiring reliable and efficient power management. Its small package and low power consumption make it an ideal choice for space-conscious and energy-efficient designs.
