ON Semiconductor NB4N1158DTR2G Product Overview

The NB4N1158DTR2G is a high-performance, low-power differential fanout buffer designed and manufactured by ON Semiconductor. This device is specifically engineered to address the needs of high-speed signal distribution and clock/data buffering applications. With its advanced design, it is capable of delivering excellent signal integrity, making it an ideal choice for use in networking, telecommunications, and computing systems where reliable and precise signal distribution is critical.

Key Features

• High-Speed Operation: The NB4N1158DTR2G supports high-frequency operation, which is essential for modern high-speed digital systems.
• Low Jitter: This device offers low output-to-output skew and low additive phase jitter, which helps in maintaining signal fidelity and timing accuracy.
• Differential Outputs: It features 1:8 differential fanout from a differential input, which can also accept single-ended input signals.
• Compatibility: The outputs are LVPECL (Low Voltage Positive Emitter Coupled Logic) compatible, allowing for easy integration with existing technologies.
• Power Efficiency: With a low-power consumption design, it contributes to the overall energy efficiency of the system it is incorporated into.
• Temperature Range: The device operates over an industrial temperature range, ensuring reliable performance under varying environmental conditions.
• Package: It is offered in a compact TSSOP-20 package, which is suitable for space-constrained applications.

Applications

The NB4N1158DTR2G is versatile and can be used in a variety of applications, including:

• Clock distribution in servers and routers
• Data distribution to multiple data paths
• High-speed networking equipment
• Signal replication in test and measurement systems
• Redundant clocking systems

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The NB4N1158DTR2G is built with this commitment in mind, ensuring that it meets stringent quality and reliability standards. It is also backed by ON Semiconductor's technical support and expertise.
