NCP1031DR2G

Part No NCP1031DR2G
Manufacturer ON Semiconductor
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC CTRLR PWM OTP OVD HV 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Output Isolation Either
Internal Switch(s) Yes
Voltage - Breakdown 200V
Topology Boost, Flyback, Forward
Voltage - Start Up 10.2V
Supply Voltage - Operating 7.6 V to 16 V
Duty Cycle 75%
Frequency - Switching Up to 1MHz
Power (Watts) 6W
Fault Protection Current Limiting, Over Temperature
Control Features Frequency Control
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 8-SOIC
Mounting Surface Mount
Win Source Part Number 091224-NCP1031DR2G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian NCP1031DR2G CAD Model

Description

The ON Semiconductor NCP1031DR2G is a versatile and efficient integrated circuit designed for a variety of power conversion applications. This high-performance component is a member of ON Semiconductor's extensive range of power management devices, engineered to provide reliable and compact solutions for power supply systems.

Key Features

  • Integrated Power Switch: The NCP1031DR2G features an integrated high-voltage power switch, allowing for simplified circuit designs and reduced external component count. This integration helps in achieving a more compact and cost-effective power supply design.
  • Wide Input Voltage Range: It operates over a broad input voltage range, making it suitable for a variety of applications, including those that require operation from standard AC mains or high-voltage DC sources.
  • Adjustable Operating Frequency: The device offers flexibility with an adjustable operating frequency, which can be tailored to specific application requirements. This feature allows for the optimization of efficiency and the reduction of external component sizes.
  • Overcurrent and Overvoltage Protection: Built-in overcurrent and overvoltage protection ensures that the device and the end application are safeguarded against potential damage from electrical stress, enhancing the system's reliability and longevity.
  • Thermal Shutdown: The NCP1031DR2G includes thermal shutdown functionality, which protects the IC from overheating by automatically turning off the power switch if the junction temperature exceeds safe operating limits.
  • Low Standby Power: It is designed for low standby power consumption, making it ideal for energy-sensitive applications where minimizing power usage during idle or standby modes is critical.

Applications

The NCP1031DR2G is suitable for a wide range of applications, including but not limited to isolated and non-isolated flyback and forward converters, auxiliary power supplies, and power supplies for PoE (Power over Ethernet) devices. Its robust design and integrated features make it a preferred choice for designers looking to create efficient, compact, and reliable power solutions.

Package and Availability

This device is available in a compact SOIC-8 package, which is ideal for space-constrained applications. The NCP1031DR2G is part of ON Semiconductor's GreenLine™ product portfolio, which represents the company's commitment to environmentally friendly and lead-free manufacturing processes.
