The NCP1060BD100R2G is a high-performance integrated circuit from ON Semiconductor, designed to facilitate efficient and compact power conversion solutions. This versatile product integrates a fixed-frequency current-mode controller with a 100 kHz switching frequency and a 700V MOSFET, making it an excellent choice for a wide range of power applications, particularly in the realm of isolated and non-isolated flyback converters.

Key Features

• Integrated 700V MOSFET: Allows for robust and reliable operation in high-voltage environments, reducing the need for additional external components and simplifying design.
• Fixed Frequency Operation: At 100 kHz, the device ensures stable performance, reduced noise, and easier filtering compared to variable frequency controllers.
• Current-Mode Control: Provides fast transient response and simplified loop compensation for improved overall performance.
• Adjustable Overcurrent Protection: Enhances safety and reliability by preventing damage due to overcurrent conditions.
• Frequency Jittering: Reduces EMI emissions, facilitating compliance with electromagnetic compatibility (EMC) regulations.
• Built-in Soft-Start: Minimizes inrush current during startup, contributing to the longevity of the device and the system.
• Under-Voltage Lockout (UVLO): Ensures the device operates only when the supply voltage is within an acceptable range, protecting the circuit.

Applications

The NCP1060BD100R2G is designed for use in a variety of applications where efficient power conversion is required. It is particularly well-suited for:

• AC-DC adapters and power supplies
• Offline battery chargers
• Standby power supplies
• Auxiliary power supplies for home appliances
• Industrial and consumer electronic devices

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the NCP1060BD100R2G is no exception. It is manufactured to meet high standards of performance and reliability, ensuring that it can withstand the rigors of real-world applications. Whether you are developing a new power supply design or upgrading an existing one, the NCP1060BD100R2G offers a compact, efficient, and reliable solution that can help streamline your product development process.
