ON Semiconductor NCP1117ST33T3G Voltage Regulator

The NCP1117ST33T3G is a robust, high-performance voltage regulator from ON Semiconductor, designed to deliver a fixed output voltage of 3.3V with a maximum output current of up to 1A. This component is a member of the NCP1117 series, which are positive linear voltage regulators that are capable of providing a very stable and reliable supply voltage for various electronic applications.

Key Features

• Output Voltage: Fixed 3.3V output to power a wide range of devices requiring stable voltage.
• Output Current: Capable of delivering up to 1A, making it suitable for high current applications.
• High Accuracy: Offers an output voltage accuracy of ±1%, ensuring precise voltage regulation.
• Thermal Performance: Features an excellent thermal behavior which allows for stable operation over a wide range of temperatures.
• Low Dropout Voltage: Low dropout performance ensures efficient operation even with a small voltage difference between the input and output.
• Protection Features: Comes with built-in thermal shutdown and current limit features to protect the device under extreme conditions.
• Package: Available in the SOT-223 package, which is suitable for surface mount technology and provides good heat dissipation.

Applications

The NCP1117ST33T3G is ideal for a variety of applications that require a stable and reliable power supply. It is commonly used in:

• Consumer Electronics
• Telecommunication Devices
• Computer Systems and Peripherals
• Portable Devices
• Power Management Circuits

Quality and Reliability

ON Semiconductor is known for its commitment to quality and the NCP1117ST33T3G is no exception. This voltage regulator is manufactured to the highest standards, ensuring that it meets the rigorous demands of industrial and commercial use. With ON Semiconductor's expertise in power management solutions, the NCP1117ST33T3G is a reliable choice for designers looking for a dependable voltage regulator for their electronic projects.
