ON Semiconductor NCP1378PG PWM Current-Mode Controller

The NCP1378PG from ON Semiconductor is a high-performance, fixed-frequency current-mode controller designed for a wide range of power supply applications. This versatile component integrates a host of features to simplify the design of flyback and forward converters, particularly in applications such as AC-DC adapters, offline battery chargers, and auxiliary power supplies.

At the heart of the NCP1378PG is its PWM (Pulse Width Modulation) control circuitry, which allows for precise control over the power delivery by adjusting the duty cycle of the output. This ensures efficient operation and helps maintain stability across varying load conditions. The device operates at a fixed frequency of 65 kHz, striking a balance between efficiency and manageable EMI (Electromagnetic Interference).

One of the key advantages of the NCP1378PG is its built-in Auto-Recovery Overcurrent Protection (OCP). This feature helps to protect the power supply and the end application from damage due to excessive current. The controller automatically restarts after an overcurrent event, ensuring continuous operation without the need for manual intervention.

The NCP1378PG also includes a Dynamic Self-Supply (DSS) feature, which eliminates the need for an auxiliary winding or external bias supply. This simplifies the power supply design and can help reduce overall component count and system cost. Additionally, the device offers an internal soft-start function, which reduces the stress on the power supply during startup by gradually increasing the output voltage to its nominal level.

With its high-voltage startup current source, the NCP1378PG is capable of starting up from a wide input voltage range, making it suitable for universal input applications. The controller also integrates frequency foldback and skip mode at light loads, which significantly improves efficiency by reducing switching losses when the power demand is low.

The NCP1378PG is available in a PDIP-7 package, which is designed to withstand high-voltage isolation, making it ideal for offline power supply applications. With its comprehensive set of features and robust design, the NCP1378PG from ON Semiconductor is a reliable choice for designers looking to create efficient and durable power supply solutions.
