ON Semiconductor NCS2200AMUT1G Operational Amplifier

The NCS2200AMUT1G from ON Semiconductor is a high-performance operational amplifier designed for a wide range of applications. This precision op-amp is ideal for use in battery-powered devices due to its low power consumption and wide supply voltage range. It offers an excellent combination of low offset voltage, low input bias current, and low quiescent current, making it a great choice for sensor interfacing, portable equipment, and other applications where power efficiency is crucial.

Key Features

• Low Offset Voltage: The NCS2200AMUT1G boasts a low input offset voltage, which ensures high accuracy in signal amplification, making it suitable for precision applications.
• Low Power Consumption: With a quiescent current of just 17 µA, this operational amplifier is optimized for battery-operated devices where power conservation is essential.
• Wide Supply Voltage Range: It operates over a wide supply voltage range from 1.8V to 5.5V, providing design flexibility for various applications.
• Rail-to-Rail Output: The device features rail-to-rail output swing, which maximizes the dynamic range within the given supply voltage.
• Extended Temperature Range: The operational amplifier is designed to operate over an extended temperature range from -40°C to +125°C, making it suitable for industrial applications.

Applications

• Portable and battery-powered devices
• Sensor interfaces
• Analog to digital converter (ADC) buffer
• Active filtering
• Medical devices
• Power supply control

The NCS2200AMUT1G operational amplifier is available in an ultra-small 5-pin SC-70 package, which is ideal for space-constrained applications. Its superior performance characteristics and small form factor make it an excellent choice for designers looking to optimize their systems for power efficiency and precision.

ON Semiconductor's commitment to quality ensures that the NCS2200AMUT1G meets the stringent requirements of modern electronic systems, providing a reliable and efficient solution for amplification needs.
