ON Semiconductor NTD3055L104T4G Product Overview

The NTD3055L104T4G is a high-performance N-Channel Power MOSFET produced by ON Semiconductor, a renowned leader in the semiconductor industry. This power MOSFET is designed to meet the stringent requirements of modern electronic circuits, offering a combination of low on-resistance and high switching performance. It is widely used in applications such as power management, DC-DC converters, motor control, and other high-efficiency power conversion and switching designs.

Key Features

• Low On-Resistance: The device boasts an exceptionally low drain-to-source on-resistance (R<sub>DS(on)) of just 52 mΩ at V<sub>GS = 10 V, reducing power losses and improving efficiency.
• High Current Capability: With a continuous drain current (I<sub>D) of 12 A, the NTD3055L104T4G can handle high current applications with ease.
• Advanced Technology: Utilizing ON Semiconductor's latest trench technology, this MOSFET ensures optimal performance and reliability.
• Low Gate Charge: The device has a low total gate charge (Q<sub>g), which results in faster switching speeds and reduced switching losses.
• Thermal Performance: The NTD3055L104T4G is encapsulated in a robust package that offers excellent thermal characteristics, ensuring stable operation under varying conditions.
• RoHS Compliant: This product is fully RoHS compliant, making it suitable for use in environmentally sensitive applications.

Applications

The versatility of the NTD3055L104T4G makes it suitable for a wide array of applications, including:

• Power supply circuits
• DC to DC converters
• Power inverters
• Motor control systems
• Automotive applications
• Switching regulators

The NTD3055L104T4G from ON Semiconductor is a testament to the company's commitment to providing high-quality, reliable components for advanced electronic systems. Its robust design and outstanding electrical characteristics ensure that it is a preferred choice for engineers and designers looking to optimize their power management solutions.
