ON Semiconductor NUP2105LT1G - ESD Protection Diode

The NUP2105LT1G from ON Semiconductor is a cutting-edge ESD protection device designed to safeguard your sensitive electronic circuits from electrostatic discharge (ESD) and other transient voltage events. This robust component is ideal for high-speed data line and signal line protection in a wide array of applications, including consumer electronics, computer peripherals, and communication systems.

Key Features

• Transient Protection: The NUP2105LT1G is capable of dissipating ESD strikes at ±20 kV, ensuring that your devices remain safe from sudden and extreme voltage spikes.
• Low Capacitance: With a typical capacitance of only 3 pF, this diode provides excellent signal integrity, making it suitable for protecting high-speed data lines without significant signal degradation.
• Bi-directional Design: It offers symmetrical ESD protection for data lines that can experience positive or negative transient voltages, enhancing its versatility in various circuit configurations.
• Low Leakage Current: The NUP2105LT1G boasts a low leakage current of less than 0.1 µA, contributing to energy efficiency in your electronic designs.
• ISO 7637-2 and IEC 61000-4-2 Compliance: This diode meets the stringent requirements of automotive and industrial standards, making it suitable for applications that demand high reliability and performance under stress.
• SOT-23 Package: The compact SOT-23 package allows for efficient use of PCB space, making it an excellent choice for space-constrained applications.

Applications

• USB interfaces
• Portable electronics
• Serial and parallel ports
• Microcontroller input protection
• Cellular phones and accessories
• Networking and telecommunications equipment

The NUP2105LT1G offers a comprehensive solution to protect sensitive electronics against the damaging effects of ESD and other voltage transients. Its combination of low capacitance, high transient voltage protection, and compliance with international standards makes it an indispensable component for designers looking to enhance the durability and reliability of their products.

With ON Semiconductor's commitment to quality and performance, the NUP2105LT1G stands out as a superior choice for ESD protection in a multitude of applications. It ensures that your electronics continue to operate smoothly, even in the face of challenging environmental conditions.
