Part No AS3685A
Manufacturer OSRAM Opto Semiconductors Inc.
Catalog PMIC - LED Drivers
Description IC LED DRIVER RGLTR 1A 10DFN
Datasheet
AS3685A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - LED Drivers
Mfr OSRAM Opto Semiconductors Inc.
Package Tape & Reel
Product Status Obsolete
Type DC DC Regulator
Topology Switched Capacitor (Charge Pump)
Internal Switch(s) Yes
Number of Outputs 1
Voltage - Supply (Min) 3V
Voltage - Supply (Max) 5.5V
Current - Output / Channel 1A (Flash)
Frequency 1MHz
Applications Camera Flash
Temperature Range - Operating -30°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 10-VFDFN Exposed Pad
Supplier Device Package 10-DFN (3x3)
Base Product Number AS3685
Standard Package 6,000 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 564686-AS3685A
Ultra Librarian 3D Model Ultra Librarian AS3685A CAD Model

Description

The AS3685A is a DC-DC regulator integrated circuit designed for power management of LED drivers in camera flash applications.

  • Feature: Internal switch
  • Topology: Switched capacitor (charge pump)
  • Current Output: 1A for flash applications
  • Voltage Range: 3V to 5.5V
  • Mounting: Surface mountable
  • Package: 10-VFDFN exposed pad
  • Manufacturer: OSRAM Opto Semiconductors Inc.
  • Product Line: Obsolete
  • Moisture Sensitivity Level: 3 (168 Hours)
