DSC300100L Real Image DSC300100L Real Image1 DSC300100L Real Image2
Same model may have multiple batches, images only for reference.
DSC300100L Real Image DSC300100L Real Image1 DSC300100L Real Image2
DSC300100L Real Image DSC300100L Real Image1 DSC300100L Real Image2
Same model may have multiple batches, images only for reference.

DSC300100L

Part No DSC300100L
Manufacturer Panasonic
Catalog Transistors (BJT) - Single
Description TRANS NPN 50V 0.1A SSSMINI3
Datasheet
DSC300100L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 100mA
VCEO Maximum Collector-Emitter Breakdown Voltage 50V
Max Vce (sat) 300mV @ 10mA, 100mA
Collector Cut-off Current(Max) 100μA
Typical Gain (hFE) (Min) 210 @ 2mA, 10V
Maximum Power Dissipation 100mW
Frequency - Transition 150MHz
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package SSSMini3-F2-B
Win Source Part Number 080806-DSC300100L
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian DSC300100L CAD Model

Description

DSC300100L

The DSC300100L is a state-of-the-art component optimized for efficiency in modern electronic projects. Its versatile nature makes it ideal for a range of applications.

  • Applications/Projects:
    • Embedded systems
    • Consumer electronics
    • Wireless communication devices
  • Features & Benefits:
    • Reliable performance
    • Energy-efficient design
    • Compact footprint for space-saving
    • High thermal stability
  • Additional Details:
    • Seamless integration with existing systems
    • Meets international safety standards
    • Extended operational lifespan
