Same model may have multiple batches, images only for reference.
ECC-T3G100DG2 Real Image
Same model may have multiple batches, images only for reference.

ECC-T3G100DG2

Part No ECC-T3G100DG2
Manufacturer Panasonic
Catalog Ceramic Capacitors
Description CAP CER 10PF 4KV SL/GP SMD  /  10 pF ±0.5pF 4000V (4kV) Ceramic Capacitor SL/GP Nonstandard SMD
Datasheet
ECC-T3G100DG2 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Ceramic Capacitors
Mfr Panasonic Electronic Components
Package Tape & Reel
Product Status Obsolete
Capacitance 10 pF
Tolerance ±0.5pF
Voltage - Rated 4000V (4kV)
Temperature Coefficient SL/GP
Temperature Range - Operating -25°C ~ 105°C
Features High Voltage
Applications General Purpose
Mounting Type Surface Mount, MLCC
Package / Case Nonstandard SMD
Dimension 0.224" L x 0.177" W (5.70mm x 4.50mm)
Thickness (Max) 0.091" (2.30mm)
Base Product Number ECC-T
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.24.0020
Other Names PCC2375TR,PCC2375DKR,ECCT3G100DG2,PCC2375CT
Standard Package 3,000
Win Source Part Number 1170400-ECC-T3G100DG2
Ultra Librarian 3D Model Ultra Librarian ECC-T3G100DG2 CAD Model

Description

The 1170400-ECC-T3G100DG2 is a high-voltage ceramic capacitor from Panasonic Electronic Components.

  • Capacitance: 10 pF
  • Voltage Rating: 4000V (4kV)
  • Application: general-purpose
  • Package: tape & reel
  • Temperature Coefficient: SL/GP
  • Tolerance: ±0.5pF
  • Thickness: 0.091" (2.30mm)
  • Mounting: surface mount, MLCC
  • Series: ECC-T
  • Dimension: 0.224" L x 0.177" W (5.70mm x 4.50mm)
  • Package/Case: nonstandard SMD
  • Temperature Range: -25°C ~ 105°C
  • ECCN: EAR99
  • Failure Rate: -
  • Standard Package: 3,000
  • Manufacturer: Panasonic Electronic Components
