Same model may have multiple batches, images only for reference.
EEH-ZA1V271V Real Image
Same model may have multiple batches, images only for reference.

EEH-ZA1V271V

Part No EEH-ZA1V271V
Manufacturer Panasonic
Catalog Aluminum - Polymer Capacitors
Description CAP ALUM POLY 270UF 20% 35V SMD / 270 µF 35 V Aluminum - Polymer Capacitors Radial, Can - SMD 20mOhm 10000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum - Polymer Capacitors
Mfr Panasonic Electronic Components
Series ZA, Anti-Vibration
Package Tape & Reel
Type Hybrid
Capacitance 270 µF
Tolerance ±20%
Voltage - Rated 35 V
ESR (Equivalent Series Resistance) 20mOhm
Lifetime @ Temp. 10000 Hrs @ 105°C
Temperature Range - Operating -55°C ~ 105°C
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 375 mA @ 100 Hz
Ripple Current @ High Frequency 2.5 A @ 100 kHz
Size / Dimension 0.394" Dia (10.00mm)
Height - Seated (Max) 0.413" (10.50mm)
Surface Mount Land Size 0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Base Product Number EEH-ZA
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1337505-EEH-ZA1V271V
Ultra Librarian 3D Model Ultra Librarian EEH-ZA1V271V CAD Model

Description

The Panasonic EEH-ZA1V271V is an aluminum-polymer capacitor with a capacitance of 270 μF and a tolerance of ±20%.

  • Manufacturer: Panasonic
  • Capacitance: 270 μF
  • Tolerance: ±20%
  • Voltage Rating: 35 V
  • ESR: 20 mOhm
  • Series: ZA
  • Vibration Resistance: Yes
  • Packaging: Tape and Reel
  • Size/Dimension: 0.394" Dia (10.00mm)
  • Application: Automotive
  • Height (Seated): 0.413" (10.50mm)
  • Mounting Type: Surface Mount
  • Package/Case: Radial, Can - SMD
  • Operating Temperature: -55°C to 105°C
  • Lifetime: 10000 Hrs @ 105°C
  • Standard Package: 500
  • Win Source Part Number: 1337505-EEH-ZA1V271V
