ELL-6UH101M Real Image
Same model may have multiple batches, images only for reference.

ELL-6UH101M

Part No ELL-6UH101M
Manufacturer Panasonic
Catalog Fixed Inductors
Description FIXED IND 100UH 600MA 360MOHM SM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Panasonic
Series H
Package Tape & Reel
Product Status Obsolete
Type Wirewound
Inductance 100 µH
Tolerance ±20%
Current Rating (Amps) 600 mA
Shielding Shielded
DC Resistance (DCR) 360mOhm
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.252" L x 0.236" W (6.40mm x 6.00mm)
Height - Seated (Max) 0.197" (5.00mm)
Base Product Number ELL-6UH
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 918020-ELL-6UH101M
Ultra Librarian 3D Model Ultra Librarian ELL-6UH101M CAD Model

Description

The Panasonic 918020-ELL-6UH101M is a fixed inductor from the H series. It is a wirewound type inductor with a shielding feature.

  • Package: tape and reel
  • Size/Dimension: 0.252" L x 0.236" W (6.40mm x 6.00mm)
  • Inductance: 100 µH
  • Tolerance: ±20%
  • Maximum Seated Height: 0.197" (5.00mm)
  • Standard Package: 1,000 pcs
  • DC Resistance (DCR): 360mOhm
  • Current Rating: 600 mA
  • Inductance Frequency Test: 100 kHz
