ST2-DC5V-F Real Image
Same model may have multiple batches, images only for reference.

ST2-DC5V-F

Part No ST2-DC5V-F
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GENERAL PURPOSE DPST 8A 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 47.6mA
Coil Voltage 5VDC
Contact Form DPST (2 Form A)
Contact Rating (Current) 8A
Switching Voltage 380VAC, 250VDC - Max
Turn On Voltage (Max) 4 VDC
Turn Off Voltage (Min) 0.5 VDC
Operate Time 15ms
Release Time 10ms
Features Sealed - Fully
Mounting Through Hole
Termination Style PC Pin
Coil Power 240 mW
Coil Resistance 105 Ohms
Temperature Range - Operating -40°C to 60°C
Win Source Part Number 136978-ST2-DC5V-F
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian ST2-DC5V-F CAD Model

Description

The Panasonic Electric Works electronic component is a relay product that comes with a contact form of DPST (2 Form A) and a coil voltage of 5VDC.

  • Contact Form: DPST (2 Form A)
  • Coil Voltage: 5VDC
  • Switching Voltage: 380VAC, 250VDC - Max
  • Contact Rating (Current): 8A
  • Mounting: Through Hole
  • Coil Resistance: 105 Ohms
  • Status: Limited Edition
  • Quantity per Package: 50
  • Applications: Industrial and power management
