BZT52-C51S

Part No BZT52-C51S
Manufacturer Panjit
Catalog END - OF - LIFE
Description SURFACE MOUNT SILICON ZENER DIODES
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Panjit
Win Source Part Number 1157339-BZT52-C51S
Manufacturer Homepage www.panjit.com.tw
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BZT52-C51S CAD Model

Description

The BZT52-C51S is a surface-mount Zener diode manufactured by Panjit. As an END-OF-LIFE component, it is crucial to verify availability before designing it into new projects. Zener diodes are designed to maintain a specific voltage across their terminals when reverse-biased, making them useful for voltage regulation and protection purposes.

Applications

  • Voltage Regulation: Provides a stable reference voltage for various circuits.
  • Overvoltage Protection: Protects sensitive components from voltage spikes and surges.
  • Clipping Circuits: Used to limit the voltage of a signal to a specific level.
  • Transient Voltage Suppression (TVS): Can be used for basic transient voltage suppression.
  • Voltage Shifting: Shifts a DC voltage level to another desired level.

Features

  • Zener Voltage: 51V Zener voltage (Vz).
  • Surface Mount Package: Designed for automated assembly on printed circuit boards.
  • Low Leakage Current: Minimizes current flow when the diode is reverse-biased below its Zener voltage.
  • High Surge Current Capability: Can withstand relatively high surge currents.
  • RoHS Compliant: Complies with environmental regulations.

Benefits

  • Stable Voltage Reference: Provides a consistent voltage reference for sensitive circuits.
  • Protection Against Overvoltage: Safeguards downstream components from damage due to voltage spikes.
  • Compact Size: Surface-mount package allows for high-density circuit designs.
  • Easy Assembly: Facilitates automated assembly processes.
  • Environmentally Friendly: Complies with RoHS regulations.

Additional Details

The BZT52-C51S is typically available in a SOD-323 or similar small-outline diode package. Key specifications include Zener voltage (Vz), Zener impedance (Zz), reverse leakage current (Ir), and power dissipation (Pd). It's critical to consult the manufacturer's datasheet for detailed specifications, application notes, and recommended operating conditions. Given that this component is marked as END-OF-LIFE, consider searching for a suitable replacement component from Panjit or another manufacturer. The datasheet contains essential information regarding maximum ratings, thermal characteristics, and electrical characteristics to ensure safe and reliable operation. Verify availability from distributors before using this part.
