Same model may have multiple batches, images only for reference.
2496 KR Electronics, Inc.
Same model may have multiple batches, images only for reference.

2496

Part No 2496
Manufacturer Pololu Corporation
Catalog Terminal Blocks
Description TERM BLOCK 7P 0.1" SIDE ENT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Terminal Blocks - Wire to Board
Mfr Pololu Corporation
Package Bulk
Product Status Active
Number of Levels 1
Positions Per Level 7
Pitch 0.100" (2.54mm)
Mating Orientation Horizontal with Board
Current 6 A
Voltage 150 V
Wire Gauge 18-26 AWG
Mounting Type Through Hole
Wire Termination Screw
Color Green
Standard Package 1 pcs
MSL Level Not Applicable
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 540423-2496
Ultra Librarian 3D Model Ultra Librarian 2496 CAD Model

Description

The 540423-2496 is a terminal block connector similar to the 540421-2493 but with 7 positions per level.

  • Positions per Level: 7
  • Color: green
  • Pitch: 0.100" (2.54mm)
  • Application: wire-to-board
  • Voltage Rating: 150V
  • Current Rating: 6A
  • Wire Termination: screws
  • Wire Gauge: 18 to 26 AWG
  • Mounting: through holes on the PCB
  • Manufacturer: Pololu Corporation
  • Product Status: Active
