The TOP249R is a member of the TOPSwitch-GX family from Power Integrations, designed for off-line power conversion applications. It integrates a high-voltage power MOSFET, PWM control, fault protection, and other control circuitry onto a single CMOS chip. This highly integrated design simplifies power supply design and reduces component count, making it suitable for a wide range of applications.

Applications:

• Power Supplies for Consumer Electronics: Used in DVD players, set-top boxes, and other consumer devices.
• Adapters and Chargers: Suitable for AC-DC adapters for mobile phones, tablets, and laptops.
• Industrial Power Supplies: Employed in power supplies for industrial control systems and automation equipment.
• LED Lighting: Used in LED drivers for lighting applications.

Features:

• Integrated Power MOSFET: Reduces component count and simplifies design.
• PWM Control: Provides efficient and stable power conversion.
• Auto-Restart Protection: Protects against overloads and short circuits.
• Overvoltage Protection (OVP): Prevents damage from excessive output voltage.
• Thermal Shutdown: Protects the device from overheating.
• Frequency Jittering: Reduces EMI (Electromagnetic Interference).
• EcoSmart Technology: Enables energy-efficient operation and meets global energy efficiency standards.

Benefits:

• Simplified Design: High level of integration reduces component count and simplifies power supply design.
• High Efficiency: PWM control and integrated MOSFET contribute to high energy efficiency.
• Robust Protection: Comprehensive protection features ensure reliable operation.
• Reduced EMI: Frequency jittering minimizes electromagnetic interference.
• Energy Efficient: EcoSmart technology meets global energy efficiency standards.

Technical Specifications:

• Input Voltage Range: Typically 85 VAC to 265 VAC (Universal Input)
• Output Power: Up to 44W in an open frame configuration.
• Switching Frequency: Refer to datasheet for specific value.
• Package: TO-220

The TOP249R is a highly integrated and efficient power conversion IC that simplifies power supply design while providing robust protection and meeting energy efficiency standards.
