90159-AS Preci-Dip – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

90159-AS

Part No 90159-AS
Manufacturer Preci-Dip
Catalog Contacts, Spring Loaded and Pressure
Description CONTACT SPRING LOADED SMD GOLD
Datasheet
90159-AS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Type Sleeve & Plunger (Pogo Pins)
Mounting Type Through Hole
Maximum Working Height 0.197" (5.00mm)
Minimum Working Height 0.142" (3.60mm)
Pad Layout Dimension Circular - 0.072" (1.83mm) (TH)
Operating Force - Initial 25.49gf
Operating Force - Mid Compression 61.18gf
Plunger Size 0.042" (1.07mm) Dia
Mating Cycles 40000
Contact Material Brass Alloy
Contact Finish Gold
Contact Finish Thickness 20.0µin (0.51µm)
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1507671-90159-AS
Ultra Librarian 3D Model Ultra Librarian 90159-AS CAD Model
