HX5004NL Real Image HX5004NL Real Image
HX5004NL Real Image HX5004NL Real Image
Same model may have multiple batches, images only for reference.

HX5004NL

Part No HX5004NL
Manufacturer Pulse
Catalog Pulse Transformers
Description RoHS peak reflow temperature rating 245 C | MODULE SINGLE GIGABIT LAN 24SOIC
Datasheet
HX5004NL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Pulse Electronics Network
Packaging Tube
Transformer Type Isolation and Data Interface (Encapsulated)
Mounting Style SMD
Parts Dimension 0.690" L x 0.480" W (17.53mm x 12.20mm)
Height - Seated (Maximum) 0.227" (5.76mm)
Temperature Range - Operating -40°C ~ 85°C
Weight 0.06 oz (1.71g)
Manufacturer Pack Quantity 25
MSL Level 4 (72 Hours)
Win Source Part Number 1182658-HX5004NL
Manufacturer Homepage www.pulseeng.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HX5004NL CAD Model

Description

The Pulse Electronics Network HX5004NL transformer is an isolation and data interface encapsulated transformer that operates in a temperature range of -40°C to 85°C.

  • Packaging: Tube
  • Mounting Style: SMD
  • Series: HX5004NL
  • Category: Transformers
  • Weight: 0.06 oz (1.7g)
  • Popularity: In the open market
  • Supply and Demand: Limited
  • Manufacturer Pack Quantity: 25 units
  • MSL Level: 4 (72 Hours)
  • Parts Dimension: 0.690 inches L x 0.480 inches W (17.53mm x 12.20mm)
