PF0552.684NL Real Image
Same model may have multiple batches, images only for reference.

PF0552.684NL

Part No PF0552.684NL
Manufacturer Pulse
Catalog Fixed Inductors
Description Inductor Power Shielded Wirewound 680uH/2700uH 20% 20KHz 0.81A/0.4A 1Ohm/4.1Ohm DCR Automotive
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

DC Resistance (DCR) 14.1 Ω
Depth 12.5 mm
Height 6 mm
Inductance 6.8027 H
Max DC Current 810.4 A
Maximum Operating Temperature 125 °C
Min Operating Temperature -40 °C
Radiation Hardening No
RoHS Compliant
Tolerance 20 %
Win Source Part Number 1028454-PF0552.684NL
Categories Fixed Inductors
Manufacturer Pulse
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian PF0552.684NL CAD Model

Description

The PF0552.684NL is a fixed inductor from Pulse Electronics.

  • Inductance: 6.8027 H
  • Tolerance: 20%
  • DC Resistance (DCR): 14.1 Ω
  • Height: 6 mm
  • Operating Temperature: -40°C to 125°C
  • RoHS: Compliant
  • ECCN: EAR99
