T3001T Pulse
Same model may have multiple batches, images only for reference.

T3001T

Part No T3001T
Manufacturer Pulse
Catalog Pulse Transformers
Description PULSE XFMR 1:1 100UH
Datasheet
T3001T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers - Pulse Transformers
Mfr Pulse
Package Tape & Reel
Product Status Active
Inductance 100µH
Mounting Type Surface Mount
Size / Dimension 0.300" L x 0.276" W (7.62mm x 7.00mm)
Height - Seated (Max) 0.250" (6.35mm)
Temperature Range - Operating -40°C ~ 85°C
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 351317-T3001T
Ultra Librarian 3D Model Ultra Librarian T3001T CAD Model

Description

The 351317-T3001T is a pulse transformer designed for use in transformers.

  • Product Name: 351317-T3001T
  • Type: Pulse transformer
  • Application: Transformers
  • Package: Tape & reel
  • Size/Dimension: 0.300" L x 0.276" W (7.62mm x 7.00mm)
  • Transformer Type: Not specified
  • Inductance: 100µH
  • Seated Height: 0.250" (6.35mm)
  • Standard Package: 500 pieces
  • Mounting Type: Surface Mount
  • Operating Temperature: -40°C to 85°C
  • ECCN: EAR99
  • Moisture Sensitivity Level (MSL): 1 (unlimited)
  • Win Source Part Number: 351317-T3001T
  • REACH Status: Unaffected
  • HTSUS Code: 8504.31.2000
  • Manufacturer: Pulse
  • Product Status: Active
