NP15P04SLG-E1-AY Real Image NP15P04SLG-E1-AY real image10805
Same model may have multiple batches, images only for reference.
NP15P04SLG-E1-AY Real Image NP15P04SLG-E1-AY real image10805
NP15P04SLG-E1-AY Real Image NP15P04SLG-E1-AY real image10805
Same model may have multiple batches, images only for reference.

NP15P04SLG-E1-AY

Part No NP15P04SLG-E1-AY
Manufacturer Renesas Electronics America
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 40V 15A TO-252
Datasheet
NP15P04SLG-E1-AY Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Renesas Electronics America
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 15A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 23nC @ 10V
Max Input Capacitance 1100pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.2W (Ta), 30W (Tc)
Maximum Rds On at Id,Vgs 40 mOhm @ 7.5A, 10V
Temperature Range - Operating 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-252 (MP-3ZK)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1083300-NP15P04SLG-E1-AY
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian NP15P04SLG-E1-AY CAD Model

Description

The supply and demand status of this component is sufficient.

  • Manufacturer: Renesas Electronics America
  • Win Source Part Number: 1083300
  • Technology: MOSFET
  • Polarity: P-Channel
  • Dimension: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Maximum Rds On @ Id,Vgs: 40 mOhm @ 7.5A, 10V
  • Continuous Drain Current: 15A (Ta) @ 25°C
