The NP50P04SDG-E1 is a P-channel power MOSFET from Renesas Electronics America. This MOSFET is designed for high-efficiency power management applications, offering low on-resistance and fast switching speeds. It is commonly used in DC-DC converters, load switches, and power supply circuits.

Applications

• DC-DC converters
• Load switches
• Power supply circuits
• Motor control circuits
• Battery management systems

Features

• P-Channel MOSFET
• Low on-resistance (RDS(on)) for efficient power conversion
• Fast switching speed
• Avalanche energy guaranteed
• Pb-free plating; Halogen Free
• Surface mount package

Benefits

• Improved power efficiency, reducing heat dissipation and energy consumption.
• Enhanced system reliability due to robust design and guaranteed avalanche energy.
• Simplified circuit design with easy-to-use surface mount package.
• Compliance with environmental regulations (Pb-free and Halogen Free).
• Increased power density by minimizing on-resistance.

Additional Details

The NP50P04SDG-E1 features a drain-source voltage (VDS) of -40V and a continuous drain current (ID) of -50A. It has a typical on-resistance (RDS(on)) of 8.5 mΩ at VGS = -10V. The gate-source voltage (VGS) is ±20V. The device is available in a surface-mount package. Its low on-resistance minimizes conduction losses, contributing to higher overall system efficiency. The fast switching speed reduces switching losses, further enhancing efficiency, especially in high-frequency applications. Its robust design ensures reliable operation even under demanding conditions. It is suitable for a wide range of power management applications, providing an efficient and reliable solution.
