RF2485 Real Image
Same model may have multiple batches, images only for reference.

RF2485

Part No RF2485
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF) - Adapters
Description CONN ADAPT 7/16 JACK-4.3/10 JACK
Datasheet
RF2485 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Bulk
Status Active
Adapter Type Jack to Jack
Conversion Type Between Series
Adapter Series 7/16 DIN to 4.3/10
Center Gender Female to Female
Convert From (Adapter End) 7/16 Jack, Female Socket
Convert To (Adapter End) 4.3/10 Jack, Female Socket
Impedance 50 Ohm
Style Straight
Mounting Free Hanging (In-Line)
Fastening Type Threaded, Threaded
Maximum Input Frequency 6GHz
Center Contact Plating Silver
Features Low PIM
Body Material Brass
Body Finish White Bronze
Center Contact Material Beryllium Copper
Dielectric Material Polytetrafluoroethylene (PTFE)
Mating Cycles 500
Temperature Range - Operating -65°C to 165°C
Win Source Part Number 293396-RF2485
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2485 CAD Model

Description

The Amphenol RF Division RF2485 is a 7/16 DIN to 4.3/10 jack to jack adapter with a maximum input frequency of 6GHz.

  • Maximum Input Frequency: 6GHz
  • Impedance: 50 Ohm
  • Features: low PIM
  • Mounting: threaded and free hanging (in-line)
  • Body Material: brass
  • Body Finish: white bronze
  • Center Contact Material: beryllium copper
  • Center Contact Plating: silver
  • Dielectric Material: polytetrafluoroethylene (PTFE)
  • Mating Cycle: 500
  • Intended Use: between series
  • Operating Temperature Range: -65°C to 165°C
  • Packaging: bulk
  • Alternative parts: MAX2021ETX+, TRF3701IRHC, and TRF3702IRHCRG4.
