RT7285CGJ6 Richtek USA Inc. RT7285CGJ6 real image RT7285CGJ6 label picture
Same model may have multiple batches, images only for reference.
RT7285CGJ6 Richtek USA Inc. RT7285CGJ6 real image RT7285CGJ6 label picture
RT7285CGJ6 Richtek USA Inc. RT7285CGJ6 real image RT7285CGJ6 label picture
Same model may have multiple batches, images only for reference.

RT7285CGJ6

Part No RT7285CGJ6
Manufacturer Richtek USA Inc.
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 1.5A TSOT23-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - DC DC Switching Regulators
Mfr Richtek USA Inc.
Series ACOT™
Package Tape & Reel
Product Status Active
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 4.3V
Voltage - Input (Max) 18V
Voltage - Output (Min/Fixed) 0.6V
Voltage - Output (Max) 8V
Current - Output 1.5A
Frequency - Switching 500kHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Supplier Device Package TSOT-23-6
Base Product Number RT7285
Standard Package 3,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0000
Win Source Part Number 835879-RT7285CGJ6
Ultra Librarian 3D Model Ultra Librarian RT7285CGJ6 CAD Model

Description

The RT7285CGJ6 is a DC-DC switching regulator designed for power management applications.

  • Input Voltage Range: It operates with an input voltage range of 4.3V to 18V
  • Maximum Output Voltage: and has a maximum output voltage of 8V.
  • Topology: The regulator features a buck topology
  • Switching Frequency: and a switching frequency of 500kHz.
  • Output Configuration: It has a single output with a positive configuration
  • Rectification: and supports synchronous rectification.
  • Mounting: The RT7285CGJ6 is surface mountable
  • Package: and comes in a SOT-23-6 thin or TSOT-23-6 package.
  • Temperature Range: With a temperature range of -40°C to 85°C, it can withstand harsh operating conditions.
  • Manufacturer: The RT7285CGJ6 is an active product from Richtek USA Inc.
