Products specifications Report Issue?

Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Categories Integrated Circuits
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 1.2 V to 2.4 V, 2.7 V to 4.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 500mA
Rds On (Typ) 120 mOhm
Features Load Discharge
Fault Protection Over Temperature, Reverse Current
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package VCSP50L1
Win Source Part Number 114620-BD2204GUL-E2
Family Name BD2204
Introduction Date August 08, 2012
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian BD2204GUL-E2 CAD Model

Description

Designed for advanced power efficiency, the BD2204GUL-E2 component supports a wide range of electronic devices requiring minimal power usage without compromising on output quality.

Features and Benefits

  • Optimal Power Utilization: Ensures energy savings in essential operations.
  • Compact and Lightweight Design: Suitable for modern electronic devices.
  • High System Stability: Provides consistent performance across applications.
  • Flexible Integration: Easily adaptable to custom projects.

Applications

  • Wireless Communication Devices
  • Smart Home Appliances
  • Portable Gaming Consoles
  • Remote Control Systems

With the BD2204GUL-E2, designers can achieve maximum efficiency in their projects, making it an excellent choice for emerging technologies and applications.
