The RB060M-30 is a Schottky barrier diode manufactured by Rohm Semiconductor. This diode is designed for high-speed switching applications and low forward voltage drop, which makes it ideal for use in DC-DC converters and other power management circuits.

Applications:

• DC-DC Converters: Used as a rectifier in DC-DC converters for efficient power conversion.
• Switching Power Supplies: Employed in switching power supplies for improved efficiency and reduced heat generation.
• Reverse Polarity Protection: Protects circuits from damage due to reverse polarity connections.
• Freewheeling Diode: Used as a freewheeling diode in inductive circuits.
• High-Frequency Rectification: Suitable for high-frequency rectification applications.

Features:

• Schottky Barrier Diode: Offers fast switching speed and low forward voltage drop.
• Low Forward Voltage Drop: Minimizes power loss in the diode.
• High Surge Current Capability: Withstands high surge currents.
• Small Surface Mount Package: Designed for surface mount assembly.
• RoHS Compliant: Complies with RoHS environmental standards.

Benefits:

• High Efficiency: The low forward voltage drop minimizes power loss.
• Fast Switching: Enables high-frequency operation in switching circuits.
• Protection Against Surges: Protects circuits from voltage surges.
• Easy Assembly: Surface mount package allows for easy automated assembly.
• Environmentally Friendly: RoHS compliant.

Technical Specifications:

The RB060M-30 has a repetitive peak reverse voltage (VRRM) of 30V and an average forward current (IF(AV)) of 600mA. The forward voltage (VF) is typically around 0.4V at 600mA. The surge current capability is high. The diode is available in a small surface-mount package, such as a SOD-323 or similar. Refer to the official Rohm Semiconductor datasheet for detailed electrical characteristics, performance graphs, and package dimensions.
