RF316-01SP1-01SP1-0100 Samtec Inc.
Same model may have multiple batches, images only for reference.

RF316-01SP1-01SP1-0100

Part No RF316-01SP1-01SP1-0100
Manufacturer Samtec Inc.
Catalog Coaxial Cables (RF)
Description CBL ASSY SMA PLUG TO PLUG 3.937"
Datasheet
RF316-01SP1-01SP1-0100 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Cable Assemblies - Coaxial Cables (RF)
Mfr Samtec Inc.
Package Bag
Product Status Active
Style SMA to SMA
1st Connector SMA Plug
1st Contact Gender Male
1st Connector Mounting Type Free Hanging (In-Line)
2nd Connector SMA Plug
2nd Contact Gender Male
2nd Connector Mounting Type Free Hanging (In-Line)
Length 3.937" (100.00mm)
Cable Type RG-316
Cable Impedance 50 Ohms
Overall Impedance 50 Ohms
Frequency - Max 6 GHz
Color Amber
Features Shielded
Temperature Range - Operating -50°C ~ 165°C
Base Product Number RF316-01
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8544.20.0000
California Prop 65 Warning Information
Win Source Part Number 517925-RF316-01SP1-01SP1-0100
Ultra Librarian 3D Model Ultra Librarian RF316-01SP1-01SP1-0100 CAD Model

Description

The 517925-RF316-01SP1-01SP1-0100 is a coaxial cable assembly designed for RF applications.

  • Cable Type: RG-316
  • Length: 3.937" (100.00mm)
  • Maximum Frequency: 6 GHz
  • Connector End A: SMA Plug
  • Connector End B: SMA Plug
  • Operating Temperature Range: -50°C to 165°C
  • Flammability Rating: UL94 V-0
  • Shielded: Yes
  • Package Type: Bag
