The 1285957-SFMC-125-02-S-D-K is a rectangular connector designed for board-to-board or cable applications. It belongs to the Tiger Eye™ SFMC series and has a number of positions of 50 with 2 rows.

• Positions: 50
• Rows: 2
• Connector Type: Receptacle
• Contact: Female Socket
• Feature: Pick and Place
• Positions Loaded: All
• Termination: Solder
• Fastening Type: Push-Pull
• Package: Tube
• Pitch-Mating: 0.050" (1.27mm)
• Row Spacing-Mating: 0.050" (1.27mm)
• Contact Finish-Mating: Gold with a thickness of 30.0µin (0.76µm)
• Contact Finish-Post: Tin
• Current Rating: 2.9A per contact
• Voltage Rating: -
• Temperature Range: -55°C to 125°C
• Insulation Material: Liquid Crystal Polymer (LCP)
• Supplier: Samtec Inc.
• Standard Package: 18
