The SSW series is a rectangular connector with a receptacle type connector that has a push-pull fastening type.

• Connector Type: Receptacle
• Fastening Type: Push-pull
• Position: 20
• Contact Type: Forked
• Positions Loaded: All
• Termination: Solder
• Contact Material: Phosphor Bronze
• Insulation Material: Liquid Crystal Polymer (LCP)
• Insulation Color: Black
• Style: Board to Board or Cable
• Pitch Mating: 0.100" (2.54mm)
• Contact Finish - Mating: Tin
• Contact Finish - Post: Tin
• Mounting Type: Through-Hole
• Row Spacing - Mating: 0.100" (2.54mm)
• Contact Length - Post: 0.194" (4.93mm)
• Insulation Height: 0.335" (8.51mm)
• Temperature Range: -55°C ~ 105°C
• Current Rating (Amps): 4.7A per contact
• REACH: Unaffected
• ECCN: EAR99
