Same model may have multiple batches, images only for reference.
TSM-145-02-L-DH-A Real Image
Same model may have multiple batches, images only for reference.

TSM-145-02-L-DH-A

Part No TSM-145-02-L-DH-A
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD R/A 90POS 2.54MM / Connector Header Surface Mount, Right Angle 90 position 0.100" (2.54mm)
Datasheet
TSM-145-02-L-DH-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series TSM
Package Tube
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 90
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.320" (8.13mm)
Insulation Height 0.240" (6.10mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Features Board Guide
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Base Product Number TSM-145
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 1
Win Source Part Number 1172639-TSM-145-02-L-DH-A
Ultra Librarian 3D Model Ultra Librarian TSM-145-02-L-DH-A CAD Model

Description

The Samtec Inc. TSM-145-02-L-DH-A is a header connector with male pins. Samtec Inc. TSM-145-02-L-DH-A is designed by Samtec Inc..

  • Connector Type: Header
  • Pin Type: Male
  • Positions: 90
  • Connection Style: Board to Board or Cable
  • Pitch: 0.100" (2.54mm)
  • Mounting Type: Surface Mount, Right Angle
  • Temperature Range: -55°C to 125°C
  • RoHS3 Compliant: Yes
