The TMG16CQ60F is a phase control thyristor module manufactured by SanRex Corporation. These modules are used in various power control applications requiring precise and efficient AC power regulation.

Applications

• AC Motor Speed Control
• Lighting Control
• Welding Equipment
• Power Supplies
• Soft Starters

Features

• Isolated Base Plate
• High Surge Current Capability
• High Voltage Capability
• Compact Size
• Easy Mounting

Benefits

• Provides precise control over AC power delivery.
• Offers high reliability in demanding industrial environments.
• Simplified mounting reduces assembly time and cost.
• Isolated base plate enhances safety and reduces noise.
• Compact design saves space in equipment cabinets.

Technical Specifications

The TMG16CQ60F has a voltage rating of 600V and a current rating of 16A. The isolation voltage between the base plate and the terminals is typically 2500V AC. The module features a high surge current capability, allowing it to withstand transient overloads. The operating junction temperature range is typically -40°C to +125°C. The device is typically mounted using screws and requires proper heatsinking for reliable operation. The compact size of the module allows for easy integration into various types of equipment.
