3413.0223.11 Schurter Inc.
Same model may have multiple batches, images only for reference.

3413.0223.11

Part No 3413.0223.11
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BRD MNT 5A 32VAC 63VDC 1206 / 5 A 32 V AC 63 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 1206 (3216 Metric)
Datasheet
3413.0223.11 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Fuses
Mfr SCHURTER Inc.
Series USI 1206
Package Strip
Product Status Active
Mounting Type Surface Mount
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 5 A
Voltage Rating - AC 32 V
Voltage Rating - DC 63 V
Response Time Fast Blow
Package / Case 1206 (3216 Metric)
Breaking Capacity @ Rated Voltage 63A
Melting I2t 4.65
Approval Agency cURus, VDE
Temperature Range - Operating -55°C ~ 90°C
Size / Dimension 0.126" L x 0.063" W x 0.024" H (3.20mm x 1.60mm x 0.60mm)
DC Cold Resistance 0.0096 Ohms
Base Product Number 3413.0223
Standard Package 100 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.10.0040
Win Source Part Number 20137-3413.0223.11
Ultra Librarian 3D Model Ultra Librarian 3413.0223.11 CAD Model

Description

3413.0223.11 Electronic Component

The 3413.0223.11 electronic component is designed for precision and reliability in various tech applications. This versatile component supports a range of projects, ensuring optimal performance.

Features and Benefits

  • High Durability: Built to withstand rigorous conditions.
  • Precision Engineering: Ensures accurate performance in all applications.
  • Energy Efficient: Reduces power consumption efficiently.

Applications

  • Consumer Electronics
  • Industrial Machinery
  • Automation Systems

This component stands out in today's competitive market, meeting and exceeding industry standards.
