RCLAMP0504S.TCT

Part No RCLAMP0504S.TCT
Manufacturer Semtech Corporation
Catalog TVS - Diodes
Description TVS DIODE 5VWM 25VC SOT23-6 / ESD Suppressor Diode Diode Array Uni-Dir 5V 6-Pin SOT-23 T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 25V
Peak Pulse Current(Ippm) 6A (8/20μs)
Power Dissipation - Pd 150W
Power Line Protection Yes
Applications Ethernet, USB OTG
Capacitance @ Frequency 3pF @ 1MHz
Temperature Range - Operating -55°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 027234-RCLAMP0504S.TCT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name RClamp0504S
Introduction Date June 17, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian RCLAMP0504S.TCT CAD Model

Description

The Semtech RClamp0504S.TCT is a steering rail-to-rail type circuit protection component designed for Ethernet and USB OTG applications.

  • Package: SMD (SMT)
  • Channels: four unidirectional channels
  • Features: power line protection
  • Capacitance @ 1MHz: 3pF
  • Power Dissipation: 150W
  • Peak Pulse Current (Ippm): 6A (8/20μs)
  • Maximum Clamping Voltage: 25V
  • STAND-OFF Voltage (Vwm): 5V
  • Minimum Breakdown Voltage: 6V
  • Halogen-Free: compliant
  • ECCN: compliant
  • Supply and Demand Status: balanced
  • Estimated EOL Date: 2026
