SX1257IWLTRT Real Image SX1257IWLTRT real image15310 SX1257IWLTRT Real Image
Same model may have multiple batches, images only for reference.
SX1257IWLTRT Real Image SX1257IWLTRT real image15310 SX1257IWLTRT Real Image
SX1257IWLTRT Real Image SX1257IWLTRT real image15310 SX1257IWLTRT Real Image
Same model may have multiple batches, images only for reference.

SX1257IWLTRT

Part No SX1257IWLTRT
Manufacturer Semtech Corporation
Catalog RF Transceiver ICs
Description IC RF TXRX 802.15.4 32WFQFN / Low Power Digital I and Q RF Multi-PHY Mode Transceiver
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Semtech Corporation
Packaging Reel
Type TxRx Only
RF Family/Standard 802.15.4
Modulation FHSS, FSK, OFDM, O-QPSK
Frequency 862Mhz ~ 1.02GHz
Power - Output 8dBm
Serial Interfaces SPI
GPIO 4
Supply Voltage (V) 2.7V ~ 3.6V
Current - Receiving 20mA
Current - Transmitting 58mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 32-WFQFN Exposed Pad
Manufacturer Pack Quantity 3,000
MSL Level 2 (1 Year)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803084-SX1257IWLTRT
Ultra Librarian 3D Model Ultra Librarian SX1257IWLTRT CAD Model

Description

The Semtech Corporation 803084-SX1257IWLTRT is a TxRx Only product. The product has a balance supply and demand status and comes in a manufacturer pack quantity of 3000.

  • Data Rate (Maximum): N/A
  • Power Output: 8dBm
  • Current Transmitting: 58mA
  • Current Receiving: 20mA
  • Operating Temperature: -40°C to 85°C
  • RF Family/Standard: 802.15.4
  • Modulation: FHSS, FSK, OFDM, O-QPSK
  • Serial Interface: SPI
  • GPIOs: 4
  • Package: 32-WFQFN exposed pad
