Same model may have multiple batches, images only for reference.

STW8C2SB

Name: STW8C2SB
Brand: Seoul Semiconductor Inc.
SKU: 803465
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	STW8C2SB
Manufacturer	Seoul Semiconductor Inc.
Catalog	LED Lighting - White
Description	LED WHITE SMD
Datasheet	STW8C2SB Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Optoelectronics - White LED Lighting
Mfr	Seoul Semiconductor Inc.
Series	3030
Package	Tape & Reel
Product Status	Active
Color	White
Current - Test	100mA
Voltage - Forward (Vf) (Typ)	6.1V
CRI (Color Rendering Index)	80
Current - Max	200mA
Viewing Angle	120°
Mounting Type	Surface Mount
Package / Case	1212 (3030 Metric)
Supplier Device Package	3030
Size / Dimension	0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max)	0.031" (0.80mm)
Thermal Resistance of Package	10°C/W
Base Product Number	STW8C2
Standard Package	1,000 pcs
ECCN	EAR99
HTSUS	8541.41.0000
Win Source Part Number	803465-STW8C2SB
Ultra Librarian 3D Model	Ultra Librarian STW8C2SB CAD Model

Alternative Products

Description

The Seoul Semiconductor Inc. 803465-STW8C2SB is a white LED lighting component from Seoul Semiconductor Inc.

Series: 3030
Color: White
Maximum Forward Voltage (Vf): 6.1V
Maximum Current: 200mA
Viewing Angle: 120°
Mounting Type: Surface Mount
Package: 1212 (3030 Metric)
Thermal Resistance: 10°C/W
Active Product: Yes
